Milling (.miling) = 46 Milling layers + 47 Measures layers + 20 Dimension layersĮxcellon drill (.drd) = 44 Drill layers + 45 Hole layersĬream frame component side(.pmc) = 31 Cream layers + 20 Dimension layersĬream frame solder side (.pms) = 32 Cream layers + 20 Dimension layers Silkscreen solder side (.pls) = 22 Place layers + 26 Name layers + 20 Dimension layers Solder stop solder side (.sts) = 30 Stop layers + 20 Dimension layers Solder side (.sol) = 16 Bot layers + 17 Pads layers + 18 Via layers + 20 Dimension layers Inner layers (.lox) = x Inner layers + 17 Pads layers + 18 Via layers + 20 Dimension layers Silkscreen component side (.plc) = 20 Dimension layers + 21 Place layers + 25 Name layersĬomponent side (.cmp) = 1 Top layer + 17 Pad layers + 18 Via layers + 20 Dimension layers
Solder stop component side (.stc) = 20 Dimension layers + 29 Stop layers The layer function (.file extension) consists of Eagle layer(s): Eagle layer number & function
